Semi-automatic PET Blow Moulding Machine / L-BS510(2-cavity)
Product parameters
Product introduction
L-BS510(2-cavity) Semi-automatic PET blow moulding machine is suitable for producing bottles from 100ml-6000ml. It is suitable for various PET/PP material and is widely be applied to produce mineral water, carbonated drink, beverage,medicine, cosmetic,detergent ,oil bottles etc.
Components of the machine:
|
The components of the machine:
|
Origin
|
|
PLC
|
Bothfit
|
|
Pneumatic Components
|
FESTO (Germany)
|
|
Transducer
|
YWJ-01D5L2(CN)
|
|
Temp. controller
|
CHINT,CN
|
|
Relay
|
CHINT,CN
|
|
Pipe connecting part
|
Shanghai,CN
|
|
Seals
|
Italy
|
Technical parameter
|
Technical Parameter of L-BS510(2-cavity)
|
|
Type
|
Item
|
Unit
|
Technical data
|
|
Container
|
product material
|
|
PET
|
|
container volume
|
L
|
0.05-6
|
|
theoratical output
|
pcs/hr
|
400-800
|
|
preform length
|
mm
|
360
|
|
preform diameter
|
mm
|
180
|
|
Moulding system
|
mould plate dimension
|
mm
|
420*500
|
|
max mould thickness
|
mm
|
240
|
|
clamping force
|
KN
|
180
|
|
mould opening stroke
|
mm
|
200
|
|
Air compressor
|
HP air flow
|
cbm
|
1.2
|
|
HP air pressure
|
Mpa
|
3.0
|
|
LP air flow
|
cbm
|
-
|
|
LP air pressure
|
Mpa
|
-
|
|
Machine dimenions/weight
|
power
|
KW
|
15+1
|
|
voltage
|
|
3P 220/380v
|
|
blower dimension
|
mm
|
1530*600*2000
|
|
blower weight
|
kg
|
600
|
|
heater dimension
|
mm
|
1800*500*1160
|
|
heater weight
|
kg
|
300
|
Features of the machine
1). The machine adopts revolving infrared pre-heat system, it ensures pet performs
be heated evenly.
2). The machine uses mechanical-double-arm mould clamping system which ensures the mould
be closed tightly even under high pressure and high temperature.
3).The air system has been divided into two parts: Pneumatic action part and bottle
blow part to meet the different pressure requirements for the action and blow, it
can provide sufficient and steady high pressure for blowing large irregular shaped
bottles
4).Wide -mouth and hot-filling bottles can also be made.
©
