4-cavity Semi-automatic PET bottle blowing Machine / L-BS510-4(4-cavity)
Product parameters
Product introduction
L-BS510-4(4-cavity) Semi-automatic PET bottle blowing machine is suitable for producing bottles from 100ml-1.5L in 4 cavities. It is suitable for PET/PP material and is widely be applied to produce mineral water, carbonated drink, beverage,medicine, cosmetic,detergent ,oil bottles etc.
A complete production line of L-BS510-4(4-cavity) includes:
-Blower
-heater
-air filter(2pcs)
-High pressure air compressor(1.65cbm/3.0Mpa)
-Bottle mould(500ml)
Technical parameter
|
Output
|
1800-2200pcs/hr
|
|
Bottle size
|
100ml-1.5L
|
|
Max length of bottle
|
340mm
|
|
Max diameter of bottle
|
100mm
|
|
Max mould plate size
|
500*380mm
|
|
Max mould thickness
|
110*220mm
|
|
Clamping force
|
180KN
|
|
Mould openning stroke(adjustable):
|
200mm
|
©
