Automatic Bottle Blowing Machine / L-BS510-4-ROBOT

Product parameters



Product introduction
L-BS510-4-ROBOT automatic bottle blowing machine is suitable for making 100ml-1500ml PET bottles, it is widely used to make water/juice/beverage/cosmetic/pesticide bottles with high output and efficiency.


Technical parameter

TYPE ITEM MEASUREMENT L-BS10-4-ROBOT
FINISHED PRODUCT Material PET
Volume L 0.1-1.5
Theoretical output BPH 2000-2500
Max length MM 340
Max diameter MM 100
MOLD PLATE Max mold plate size MM 500*380
Max mould thickness MM 110-200
Clamping force KN 180
Mold opening stroke MM 200
AUXILIARY HP compressor M3/MPA 1.2/30
Air filter M3/MPA 1.0/30
Heating power KW 15
DIMENSION AND WEIGHT Machine size+weight MM

1820*820*2200

1500kgs
